RUIJIE RG‑ES106D‑P V2 – 6‑PORT 10/100 MBPS UNMANAGED POE DESKTOP SWITCH
₨ 10,600
📈 Key Features
-
Unmanaged Desktop Switch: Simple plug‑and‑play operation with no configuration needed.
-
6 × 10/100 Mbps Ethernet Ports: Includes 4 PoE/PoE+ downlink ports and 2 regular uplink ports.
-
PoE/PoE+ Support: Compliant with IEEE 802.3af/at, powering PoE devices directly through Ethernet — e.g., cameras, phones, or APs.
-
PoE Power Budget: Up to ~54 W total PoE power for connected devices.
-
Unmanaged & Cloud Visible: Although unmanaged, it can be monitored via the Ruijie Cloud app for visibility.
-
Auto MDI/MDIX: Automatically adjusts for straight‑through or crossover Ethernet cables.
-
Fanless Design: Silent operation with natural heat dissipation.
| Specification | Details |
|---|---|
| Model | RG‑ES106D‑P V2 |
| Switch Type | Unmanaged PoE Desktop Switch |
| Ports | 6 × 10/100 Mbps RJ‑45 |
| PoE/PoE+ Ports | 4 PoE/PoE+ downlink; 2 uplink |
| PoE Power Budget | ~54 W total |
| Switching Capacity | ~1.2 Gbps |
| Forwarding Rate | ~0.89 Mpps |
| MAC Address Table | ~2000 entries |
| LED Indicators | Per‑port Link/Act + PoE + System |
| Power Supply | 51 V DC, ~1.11 A |
| Power Consumption | ~60.6 W (with PoE load) |
| Fan | Fanless |
| Dimensions | ~140 × 67 × 26 mm |
| Operating Temp. | 0 °C to 45 °C |
| Storage Temp. | ‑40 °C to 70 °C |
| Humidity | 10 %–90 % RH |
| Surge Protection | ~4 kV port surge protection |
🎯 Best Use Cases
✅ IP Surveillance Networks – Power and connect multiple PoE cameras without separate power injectors.
✅ Wireless AP & VoIP Deployment – Simple PoE support for APs and VoIP phones.
✅ Small Office/Home Office (SOHO) – Expand network ports while powering devices directly.
✅ Quiet & Compact Environments – Fanless design ideal for desks and noise‑sensitive spaces.
